1. Insert your hinge arms into the holes of your cabinet door and drill them into place

2. Measure from the top and bottom of the cabinet face frame 1 and 9/16 inch and 3 and 7/16 inch for the base plate screws. Use your pencil to mark that spot

3. It's easiest to measure and install both base plates first. Align the holes on the base plate with the marks you made on the cabinet. Take your drill and use the screws to securely install the base plate.

4. Once the base plates are installed, slide the top and bottom hinge arms one by one into the base plates untill you hear them click.
